Facilities
The GOFB has several infrastructures in order to cover the research works carried out and also collaborate with different research groups.
Micro/Nano Fabrication
| Equipment/Tool/System | Vendor |
|---|---|
| Micro Nano fabrication tool (Mask projection an NIL) | SUSS MICROTEC SE |
| Spin coating (x2) | LAURELL TECHNOLOGIES |
| Oxygen etcher | DIENER ELECTRONIC |
| Hot plate (x4) | OVAN (3) / AREX (1) |
| Thermal magnetic shaker | OVAN |
| Laminar flow chamber class 10 | TELSTAR |
| Mechanical plotter | SUMMA |
| 3D Printer | ULTIMAKER |
| Furnace | BINDER |
| Sputtering | LEICA |
| Fiber laser 20 W | |
| Extraction Chamber | TELSTAR |
Optical an Electrochemical Characterization
| Equipment/Tool/System | Vendor |
|---|---|
| Optical microscope (x2) | LEICA/NIKON |
| Fourier Transform Infrared (FTIR) spectroscopy | BRUKER |
| High spatial resolution beam profile reflectometer (N-GAUGE) | NIGHTINGALE-EOS |
| Thin film thickness meassuring system | FILMETRICS |
| Infrared spectrometer | MIGHTEX |
| Optical light sources | HAMAMATSU |
| Visible spectrometer | MIGHTEX |
| Optical powermeter | NEWPORT |
| Potentiostat/Galvanostat/Impedance Analyzer | METROHM |
| UV Spectrophotometer | OPTIZEN |
| Dinamic Light Scattering (DLS) | MALVERN PANALYTICAL |
Chemical / Biochemical
| Equipment/Tool/System | Vendor |
|---|---|
| Ultra High Resolution Laboratory Scale | COBOS |
| High Resolution Laboratory Scale | SARTORIUS |
| Incubator (x2) | LABNET BIOTECNICA |
| CO2 Incubator | MEMMERT |
| Biological cabin | TELSTAR |
| Portatil station for dried and particle less air | PREVOST |
| pHmeter | METTLER |
| Ultrasonic Cleaner SELECTA | FISHER SCIENTIFIC |
| Refrigerator | LIEBHERR |
| Freezer (-20 ºC) | LIEBHERR |
| Freezer (-80 ºC) | ARCTIKO |
| Refrigerated microtube centrifuge (2mL) (x2) | HETTICH/BIOCEN |
| Refrigerated tube centrifuge (15/50 mL) | VWR MEGASTAR |
| Spotter (nL) | BIODOT |
| Spotter (pL) | SCIENION |
| Biochemical chamber Bio II advance (x2) | TELSTAR |
Biochemical readout platforms
| Equipment/Tool/System | Vendor |
|---|---|
| Point of Care Device MOX (x3) | BIOD |
| Multiplexing Optical Readout Platform MOX (x2) | MULDIA |
| ELISA Plate Reader | TECAN |
| Optical Fiber Readout Platform Static Mode | GOFB |
| Optical Fiber Readout Platform Continuous Mode | GOFB |
| Multiparametric Readout Platform | GOFB |
| Organ on Chip Platform | GOFB |
Computational Modelling and Simulation
| Equipment/Tool/System | Vendor |
|---|---|
| COMSOL Multiphysics | COMSOL |
| RSOFT Photonic Design Software | SYNOPSYS |
| MATLAB | THE MATHWORKS |
| WORSTATION | |
| OWN CODES | GOFB |
